Federated Login, Authentication, and MFA Configuration

Overview​

This section describes how to set up Business-to-Business (B2B) federation with OmegaAI (OAI), focusing on federated login through OpenID and SAML Identity Providers. Federated login allows users to access multiple applications with a single set of credentials, ensuring both convenience and security. The described process includes collecting required information from the customer, coordinating policy updates with OmegaAI developers, performing customer testing, and an optional role mapping step.

Information Required​

To initiate the federated login integration, user is required to provide a list of details for authentication via OpenID and SAML Identity Providers.

OpenID​

Please provide the following details:

  • Client ID: A unique identifier for your application.

  • Secret: A secret key used to secure communication.

  • Response Type: The type of response expected.

  • Scope: The scope of access requested.

  • Response_mode: How the response is delivered to your client.

  • MetadataURL: URL containing metadata about the OpenID configuration.

  • Domain_hint: Directs the authentication request to the correct domain.

  • ClaimsMapping: Maps token claims to user attributes.

  • User Attributes: UserID, DisplayName, GivenName, SurName, and Email.

SAML​

Please provide the following details for SAML configuration:

  • WantsEncryptedAssertions: Indicates whether assertions should be encrypted.

  • WantsSignedAssertions: Indicates whether assertions should be signed.

  • PartnerEntity: The entity identifier of your SAML partner.

  • IssuerUri: The issuer's URI.

  • Domain_hint: Used to streamline the login process.

  • Certificate: Your public key certificate used for verifying SAML assertions.

  • ClaimsMapping: Maps SAML assertion attributes to user attributes.

  • User Attributes: UserID, DisplayName, GivenName, SurName, and Email.

Additionally, please add the following URL as a redirect URL in your federated application settings: <https://omegaai.b2clogin.com/omegaai.onmicrosoft.com/oauth2/authresp\>

Coordinate Policy Update with RamSoft Team​

After you have provided the necessary details, please coordinate with RamSoft Support to update the authentication policies. This coordination is crucial to integrate the new settings without causing any disruptions in service.

Perform User Testing​

Once the policy updates are completed, it is essential that you conduct thorough testing to verify the functionality of the federated login. This testing ensures all integrations are operational and secure prior to going live.

Role Mapping (Optional)​

If your organization requires role-based access, we can assist in mapping roles based on the claims provided by your Identity Provider (IDP).

role mapping
